Discover our Extruded Tubes

Extruded Tubes

Different types of materials have been used in industry over the centuries. After the discovery of a special production process, namely electrolytic melting, aluminium became widespread and completely revolutionised the world of technology and beyond.

In fact, it became increasingly possible to make tubes from this material, which could take on different shapes and sizes, thanks to the versatility of this metal alloy. In a short time, therefore, aluminium has replaced many other elements in numerous applications.

Yet what are the main benefits of aluminium extruded tubes over those made of other alloys?

What does the extrusion process consist of: let’s find out together

When we speak of aluminium tube extrusion, we are referring to the heating of this material until it becomes malleable. It is then passed through a die, which gives it the desired shape and size. This type of processing is carried out using a precise extrusion machine.

It should be noted that aluminium extruded tubes, in some cases, can also be subjected to specific treatments that enhance their corrosion resistance properties and aesthetic qualities. This involves specific processing, such as cooling and ageing treatment.

What are the main advantages of using aluminium extruded tubes?

Aluminium extruded tubes have very interesting properties, which offer several advantages in various fields of application.

First of all, it should be noted that these elements are characterised by extreme lightness. Compared to iron, in fact, these tubes weigh about one third. This characteristic does not compromise its strength. An extruded aluminium tube is very robust and can become either elastic or rigid, depending on the intended use.

These types of tubes are also characterised by important acoustic and thermal insulation, factors that prevent sound dispersion and ensure that the temperature is maintained. It should be kept in mind that this metal alloy is fireproof and therefore resistant to fire.

In recent years, aluminium extruded tubes have been increasingly demanded by various industries also due to the fact that this raw material is known to be one of the most environmentally friendly and easily recyclable in the world. In fact, these tubes can be 100 per cent recycled and can be brought back to life, thus protecting the health of the environment.

Long service life is also a distinguishing feature of aluminium extruded tubes, which are also maintenance-free. This is due to the presence of an oxide layer that protects the tubes from external chemical attacks.

Finally, it should be noted that the aluminium from which these tubes are made is very versatile and practical, as well as being known to be an excellent conductor even at high pressure.

Biography

Size Table

Product Diameter Weight
Extruded Tubes 7x1 mm 0,052
Extruded Tubes 8x0,9 mm 0,054
Extruded Tubes 10x0,9 mm 0,070
Extruded Tubes 10x1 mm 0,076
Extruded Tubes 10x2 mm 0,135
Extruded Tubes 11,5x1 0,086
Extruded Tubes 12x0,9 mm 0,084
Extruded Tubes 13x1 mm 0,103
Extruded Tubes 13,5x1 mm 0,105
Extruded Tubes 14x0,9 mm 0,100
Extruded Tubes 14x1 mm 0,110
Extruded Tubes 14x2 mm 0,204
Extruded Tubes 15x1,2 mm 0,140
Extruded Tubes 16x0,9 mm 0,115
Extruded Tubes 16x1 mm 0,128
Extruded Tubes 16x1,5 mm 0,183
Extruded Tubes 16x2 mm 0,234
Extruded Tubes 16x6,15 mm 0,513
Extruded Tubes 17,5x1 mm 0,141
Extruded Tubes 18x1,15 mm 0,143
Extruded Tubes 18x4,9 mm 0,545
Extruded Tubes 20x1 mm 0,162
Extruded Tubes 20x1,5 mm 0,238
Extruded Tubes 21x1 mm 0,170
Extruded Tubes 22x1 mm 0,179
Extruded Tubes 22x1,5 mm 0,260
Extruded Tubes 22x2 mm 0,339
Extruded Tubes 22,5x1 mm 0,184
Extruded Tubes 23x1,2 mm 0,222
Extruded Tubes 24x1 mm 0,195
Extruded Tubes 24x2 mm 0,376
Extruded Tubes 24,8x2 mm 0,387
Extruded Tubes 25x1 mm 0,203
Extruded Tubes 25x1,2 mm 0,242
Extruded Tubes 25x1,3 mm 0,261
Extruded Tubes 25x1,5 mm 0,300
Extruded Tubes 25x2 mm 0,389
Extruded Tubes 25x3 mm 0,559
Extruded Tubes 26x1 mm 0,213
Extruded Tubes 27x1 mm 0,221
Extruded Tubes 28x1 mm 0,230
Extruded Tubes 28x2 mm 0,441
Extruded Tubes 30x1 mm 0,224
Extruded Tubes 30x1,5 mm 0,362
Extruded Tubes 30 x 3 0,687
Extruded Tubes 32x1 mm 0,265
Extruded Tubes 32x1,5 mm 0,388
Extruded Tubes 33x1 mm 0,707
Extruded Tubes 34,4x1,1 mm 0,310
Extruded Tubes 35x1 mm 0,288
Extruded Tubes 35x2,5 mm 0,691
Extruded Tubes 38x2 mm 0,610
Extruded Tubes 40x1,5 mm 0,490
Extruded Tubes 40x3 mm 0,942
Extruded Tubes 40x5 mm 1,485
Extruded Tubes 40,6x1,05 mm 0,352
Extruded Tubes 42,4x1 mm 0,351
Extruded Tubes 45x2 mm 0,797
Extruded Tubes 48x3 mm 1,145
Extruded Tubes 50 x 2 0,814
Extruded Tubes 50 x 3 1,196
Extruded Tubes 50 x 4 1,561
Extruded Tubes 50x5 mm 0,969
Extruded Tubes 55x2,5 mm 1,113
Extruded Tubes 55x12,5 mm 4,506
Extruded Tubes 60x1 mm 0,500
Extruded Tubes 60x1,5 mm 0,744
Extruded Tubes 60x2 mm 0,977
Extruded Tubes 60x3 mm 1,450
Extruded Tubes 64x3,5 mm 1,796
Extruded Tubes 70x1,5 mm 0,872
Extruded Tubes 70x5 mm 2,757
Extruded Tubes 72x16 mm 7,600
Extruded Tubes 75x1,5 mm 0,937
Extruded Tubes 77x3,5 mm 2,181
Extruded Tubes 80x1 mm 0,670
Extruded Tubes 80x1,2 mm 0,802
Extruded Tubes 80x1,5 mm 0,996
Extruded Tubes 80x20 10,200
Extruded Tubes 81x17 9,229
Extruded Tubes 83x15 8,651
Extruded Tubes 85x7,2 mm 4,752
Extruded Tubes 89x15,25 mm 9,539
Extruded Tubes 90x2,5 mm 1,855
Extruded Tubes 90x3,5 mm 2,568
Extruded Tubes 90x11 7,371
Extruded Tubes 90x25 13,780
Extruded Tubes 100x7 5,530
Extruded Tubes 100x10 7,633
Extruded Tubes 102x3,5 2,924
Extruded Tubes 102x8 6,378
Extruded Tubes 110x7,5 6,521
Extruded Tubes 115x3 mm 2,850
Extruded Tubes 115x3,5 mm 3,310
Extruded Tubes 120x5 4,876
Extruded Tubes 120x8 7,601
Extruded Tubes 120x10 9,331
Extruded Tubes 120x16 14,200
Extruded Tubes 120x42 26,795
Extruded Tubes 130x15 14,631
Extruded Tubes 132x11 11,300
Extruded Tubes 132x16 15,740
Extruded Tubes 140x10 11,030
Extruded Tubes 140x35 31,180
Extruded Tubes 150x5 6,151
Extruded Tubes 150x8 9,636
Extruded Tubes 150x10 11,875
Extruded Tubes 150x12,5 14,600
Extruded Tubes 150X15 17,177
Extruded Tubes 150x17,5 19,700
Extruded Tubes 150x25 26,500
Extruded Tubes 152x38,5 37,070
Extruded Tubes 155x17 19,900
Extruded Tubes 160X10 12,720
Extruded Tubes 160x15 18,440
Extruded Tubes 160x20 23,750
Extruded Tubes 165x35 38,600
Extruded Tubes 170x10 13,573
Extruded Tubes 170x25 30,750
Extruded Tubes 170x35 40,079
Extruded Tubes 180x10 14,421
Extruded Tubes 180x12 17,100
Extruded Tubes 180x32,5 40,700
Extruded Tubes 181x27 35,268
Extruded Tubes 184x14,5 19,303
Extruded Tubes 185x10 14,850
Extruded Tubes 190x10 15,300
Extruded Tubes 197x25 36,470
Extruded Tubes 194x21 30,900
Extruded Tubes 200x10 16,116
Extruded Tubes 200x12 19,600
Extruded Tubes 200x15 23,540
Extruded Tubes 200x25 e 203x25,4 39,000
Extruded Tubes 203x16,5 26,300
Extruded Tubes 203x42,5 57,900
Extruded Tubes 205x10 16,550
Extruded Tubes 210x10 16,970
Extruded Tubes 210x15 24,820
Extruded Tubes 210x20 32,230
Extruded Tubes 218x16,5 28,202
Extruded Tubes 220x15 26,100
Extruded Tubes 220x16 27,700
Extruded Tubes 224x43 66,100
Extruded Tubes 228x14 25,400
Extruded Tubes 230x10 18,700
Extruded Tubes 230x15 27,356
Extruded Tubes 230x16 29,100
Extruded Tubes 230x30 50,890
Extruded Tubes 232x21 37,600
Extruded Tubes 235x12,5 23,593
Extruded Tubes 240x30 53,500
Extruded Tubes 244x17 32,800
Extruded Tubes 250x5 10,390
Extruded Tubes 250x7 14,450
Extruded Tubes 250x8 16,430
Extruded Tubes 250x12 24,230
Extruded Tubes 250x20 39,100
Extruded Tubes 250x35 64,300
Extruded Tubes 250x50 84,800
Extruded Tubes 253x16 32,170
Extruded Tubes 254x6 12,630
Extruded Tubes 260x3 6,800
Extruded Tubes 260x13 27,700
Extruded Tubes 260x32,5 62,715
Extruded Tubes 262x6 13,100
Extruded Tubes 262x35,75 68,700
Extruded Tubes 262,5x5 10,920
Extruded Tubes 268x41,5 79,731
Extruded Tubes 270x15 32,450
Extruded Tubes 273,05x18,26 39,500
Extruded Tubes 279,4x19,05 42,068
Extruded Tubes 280x7 16,210
Extruded Tubes 285x18 40,760
Extruded Tubes 300x10 24,600
Extruded Tubes 303x18 43,600
Extruded Tubes 303x26,5 62,200
Extruded Tubes 310x8 20,500
Extruded Tubes 310x30 71,250
Extruded Tubes 312,5x5 13,040
Extruded Tubes 315x7,5 19,600
Extruded Tubes 315x15 38,200
Extruded Tubes 320x25 62,600
Extruded Tubes 330x12,5 33,700
Extruded Tubes 340x8 22,530
Extruded Tubes 350x15 42,625
Extruded Tubes 350x18 50,700
Extruded Tubes 392x6 19,645
Extruded Tubes 398x7 23,300
Extruded Tubes 400x10 33,080
Extruded Tubes 400x15 49,986
Extruded Tubes 412x26 85,200
Extruded Tubes 434x7 25,352
Extruded Tubes 442x 11 40,300
Extruded Tubes 450x10 37,330
Extruded Tubes 450x12 44,600
Extruded Tubes 454x10 37,650
Extruded Tubes 466x10,8 41,800
Extruded Tubes 493x11,6 48,000
Extruded Tubes 495x12,5 51,150
Extruded Tubes 500x15 61,709
Extruded Tubes 521x15 64,381
Extruded Tubes 542x57 235,000
Extruded Tubes 550x10 45,800
